Vertical Marble Launcher Diagram

The object s vertical displacement as a function of time.

Vertical marble launcher diagram.

Uff that was a lot of calculations. Cart eventually lands at point z. Shown in the diagram to the right. Attach one photogate to the marble launcher so that the marble breaks the light beam as it comes out of the barrel.

The vertical velocity changes by 9 8 m s each second of motion. T 2 vy g range of the projectile. A marble launcher shoots a marble horizontally from the height of 0 2 m above a horizontal floor. On the other hand the horizontal acceleration is 0 m s s and the projectile continues with a constant horizontal velocity throughout its entire trajectory.

Put the timer in interval mode and connect the photogate to input a. This angle will be the angle θ of the initial velocity v o. Compare the time it takes for the cart to travel from x to z. Projectiles are objects upon which the only force is gravity.

Use the graph to the right for questions 6 through 8. C setting up the marble launcher c 1 1. Vx v cos α vertical velocity component. Vy v sin α time of flight.

Use the diagram to the right to answer question 11 14 it represents a cart that is rolling along a tabletop at a constant velocity and a ball that will chop et the instant the cart rolls off the cclgc of the tabletop. Procedure for the horizontal launch to find the device launch velocity. Projectile motion lab purpose determine the initial velocity of ball launched horizontally predict and verify the range of ball launched at an angle equipment. Place the cpo launcher near the edge of a student desk.

For this experiment you will use angles. Launching the object from the ground initial height h 0. The launcher can launch at angles from 0 horizontal to 90 degrees vertical. Use this diagram to answer questions 28 through 30.

The angle can be changed by untightening the large knob on the rear of the launcher arm of the marble launcher and rotating the launcher arm to the appropriate angle then retightening the knob. The marble launcher has different angle settings from 0 to 90. Stopwatch might be needed for part 2. Marble either a plastic or steel marble my group selects the marble meter stick.
